图象传感器\Image Sensor

1/3〞SONY CCD

  有效像素\Effective Pixels

PAL:512(H)×582(V)    NTSC: 512(H)×492(V)

  感光面积\Sensing Area

3.6×2.7mm

  信号系统\Signal System

PAL/NTSC

  水平清晰度\Horizontal Resolution

420TV lines

  快门速度\Shutter Speed

1/50(1/60)—1/100,000sec

  白平衡\White Balance

Auto white balance

  信噪比\S/N Ratio

More than 48db(AGC OFF)

  最低照度\Minimum Illumination

0Lux At Night(LED ON)

  视频输出\Video Output

1.0Vp-p,75Ω

  电源供给\Power Requirement

DC 12V±10%  350MA

  工作温度\Operation Temperature

-10℃~+50℃ RH95%Max

  同步方式\Sync System

Internal Synchronization

  视频接口\Video Out

BNC

  尺寸\Dimensions

Φ75×70mm

  净重/毛重\NW/GW

240g/280g

  红外灯数量\LED number

Φ5 24PCS

  红外灯距离\Infraed Lamps

30m
