图象传感器\Image Sensor

1/4〞SHARP CCD  1/3 SONY CDD

  有效像素\Effective Pixels

PAL:512(H)×582(V)    NTSC: 512(H)×494(V)

  信号系统\Signal System

PAL/NTSC

  水平清晰度\Horizontal Resolution

420TV lines

  快门速度\Shutter Speed

1/50(1/60)—1/100,000sec

  白平衡\White Balance

Auto white balance

  信噪比\S/N Ratio

More than 48db(AGC OFF)

  最低照度\Minimum Illumination

1.0Lux /F1.2

  视频输出\Video Output

1.0Vp-p,75Ω

  电源供给\Power Requirement

DC12V

  红外灯数量\LED number

Φ5 12PCS

  红外灯距离\Infraed Lamps

12m

  尺寸\Dimensions

Φ100×58mm

  净重/毛重\NW/GW

150g/210g
